Three convincing arguments for Cablelock AS Professional- Installable without removing old hose line.
- Universal system, a few types covering all the hose sizes.
- Compact structure, to be also installed in narrow spaces.
|
|
|
|
|
|
|
|
|
Cablelock AS2 Mini
New in 2016!
|
|
|
|
|
|
|
|
|
Cablelock AS INOX
New in 2017!
100% stainless
|
|
|
|
|
|
|
This new protection system facilitates the application of the current safety standards, the most important ones are listed below:
|
- DGUV 113-020 (formerly BGR237)
- DIN EN ISO 4413
- Machine directive 2006/42/EG
- TRBS 2111
|
- DIN EN 201
- DIN EN SIO 12100
- BGI/GUV-I 5100
- BGR 221
|
|
Abstract from DIN EN ISO 4413:'....If the failure of a hose line causes a hazard due to whipping, the hose line has to be restrained or shielded by suitable means...'
|
Cablelock AS is an innovative retaining system (whip check) for high-pressure hoses, which protects person and machinery from dangerous lash effect when the hose tears apart. The end of the hose slides out or tears apart from the crimp fitting. This is where the german definition 'Ausreißsicherung' (retaining system), or in short 'AS' comes from. According to DIN EN 201, dangerous hydraulic hoses have to be fastened in case that they reach an operating pressure above 50bar, if they are not crimped with interlock fittings (tear-proof fittings).
The cablelock retaining systems are also available in stainless steel (AISI 303, AISI 316.)
|
Cablelock retaining systems are exclusively tested for liquid media. All pressure specifications are therefore exclusively applicable to liquid media. No warranty shall be assumed for applications with compressible media (gases, air etc.)!
|
